Description
Included
-
Grass blade: Grass 255-4
-
Harness: Single harness
-
Trimmer head: T25 (L)
Not included
-
Saw blade
| T25 + Grass255-4t, US49, CA | |
|---|---|
| 970 73 25‑03 | |
| Engine | |
| Cylinder displacement | 1.32 cu.inch |
| Power output | 0.8 hp |
| 1 | |
| Fuel tank volume | 10.14 fl oz (US) |
| Fuel tank volume | 0.3 l |
| Fuel Consumption | 630 g/kWh |
| Maximum power speed | 7,800 rpm |
| Idling speed | 2,800 rpm |
| Maximum rpm output shaft | 7,200 rpm |
| Electrode gap | 0.02 in |
| Clutch engagement speed (±120) | 4,200 rpm |
| Torque, max. | 0.8 Nm |
| Torque, max. at rpm | 6,000 rpm |
| Spark Plug | Husqvarna HQT-4 672201 |
| Output shaft thread | M10x1.25V |
| Equipment | |
| Grass blade | Grass 255-4 |
| Harness | Single harness |
| Saw blade | Not included |
| Trimmer head | T25 (L) |
| Handle type | Loop |
| Control | |
| Connectivity | Not applicable |
| Capacity | |
| Cutting width | 17 in |
| Transmission | |
| Gear ratio | 0.68 |
| Drive gear angle | 30 ° |
| Dimensions | |
| Tube diameter | 1 in |
| Weight (excl. cutting equipment) | 10.14 lbs |
| Tube length | 57.677 in |
| Lubricant | |
| Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
| Lubricant type (bevel gear) | Mineral grease |
| Sound and noise | |
| Sound pressure level at operators ear (LpA) | 90 dB(A) |
| Sound power level, guaranteed (LWA) | 0 dB(A) |
| Sound power level, measured | 97.8 dB(A) |
| Emission | |
| Exhaust emissions (HC average) EU | 42.02 g/kWh |
| Exhaust emissions (HC average) CARB | 31.56 g/kWh |
| Exhaust emissions (HC average) | 42.02 g/kWh |
| Exhaust emissions (CO average) EU | 230.89 g/kWh |
| Exhaust emissions (CO average) | 254.87 g/kWh |
| Exhaust emissions (CO average) CARB | 30.3 g/kWh |
| Exhaust emissions (NOx average) EU | 2.98 g/kWh |
| Exhaust emissions (NOx average) | 2.98 g/kWh |
| Exhaust emissions (NOx average) CARB | 1.82 g/kWh |
| Vibration | |
| Equivalent vibration level (ahv, eq) left handle | 0 m/s² |
| Equivalent vibration level (ahv, eq) right handle | 0 m/s² |
